    What type of tool is mud gun?

    Time: 2024-08-08 Source: Author: HL Solidscontrol

    Mud tank mud gun, also known as drilling fluid gun, is used in mud solid control system. It is mainly used in drilling mud circulation system to flush and stir the dead corners in the drilling fluid circulation tank that the mud mixer cannot stir. The drilling fluid in the circulation tank is fully stirred and mixed to make the solid phase particles in the drilling fluid evenly suspended, which is convenient for the graded separation of drilling fluid purification systems at all levels to prevent mud from settling in the drilling mud tank. At the same time, the mud gun can also be used in conjunction with the drilling fluid mud shear pump. It is used for mud transportation between bins in the mud system, which can combine and coordinate the drilling fluid mud of each solid control system, making the entire solid control system a unified whole.
    Mud tank mud gun

    The drilling fluid mud gun is independently produced by our company for the ZJ drilling rig mud solid control system. It is mainly used in the drilling fluid mud circulation system. At the same time, the equipment can also be used in conjunction with the drilling fluid mud shear pump. It is a special tool to prevent mud from settling in the drilling mud tank. It can prevent mud from settling in the dead corners of the mud tank. The equipment has a simple structure, flexible operation and convenient use. It is an ideal solid control equipment to prevent mud sedimentation.

    The drilling mud gun is also called the drilling fluid gun. The main function of the drilling mud gun is to perform high-pressure jet mixing in the mud tank, flush and stir the dead corners in the drilling fluid circulation tank that the mud mixer cannot stir, and fully mix the mud in the mud tank to make the solid phase particles in the drilling fluid evenly suspended, which is convenient for the graded separation of mud purification equipment at all levels, and prevents the solid phase precipitation in the corners of the mud tank and the suction port of each pump. It can also be used to transport mud between warehouses.

    Drilling mud guns are mainly divided into two types: high pressure and low pressure, and are generally placed on the top of the mud tank. High-pressure drilling mud guns have small displacement and high pressure, and are generally supplied by drilling pumps. Low-pressure drilling mud guns are generally supplied by mud pumps, with large displacement and low pressure.

    There are two aspects to pay attention to when using a drilling mud gun:

    1. Pay attention to ensuring the cleanliness of the drilling mud gun nozzle to prevent the mud nozzle from being blocked.

    2. Pay attention to adjust the size of the gate valve in real time according to the density of the mud.
