How to maintain the mud-gas separator
Time: 2024-05-23 Source: Solids Control Equipment Author: Mrek
The mud-gas separator is a common solid control equipment, mainly used to remove harmful gases in the drilling fluid and prevent the occurrence of well kicks. It is particularly important for drilling safety. The mud-gas separator should be maintained as follows after use:
After using the mud-gas separator, all drain valves should be opened to promptly drain the drilling fluid or clean water remaining in the separator tank and the drain and exhaust pipes, and then the inside of the mud-gas separator should be cleaned with clean water.
Check, tighten, and maintain the connecting bolts and pressure plate bolts. During winter construction, insulation and antifreeze measures should be taken for the mud-gas separator inlet pipe, drain valve, etc.
After the mud-gas separator has been used on site for one year, the well control equipment maintenance unit should inspect and repair the mud-gas separator and issue an inspection and maintenance report.
After the use of the mud-gas separator for more than three years, the liquid-gas separator should be inspected internally and externally by an organization with inspection qualifications in accordance with the requirements of the "Special Equipment Safety Technical Specifications: Safety Technical Supervision Regulations for Stationary Pressure Vessels" (TSG21-2016). If the corrosion rate of the main material of the separator is greater than 0.3mm/year, the internal and external inspection cycle should be appropriately shortened.
The safety valve and pressure gauge of the mud-gas separator should be calibrated once a year. To ensure that the performance parameters of the equipment are accurate.
HL Petroleum is a professional manufacturer of solid control equipment. HL mud separators are suitable for multiple industries such as oil drilling, urban construction, shield tunneling, piling mud, etc. The equipment quality is guaranteed to be cost-effective and sold well in many countries around the world. If you have any needs, please contact us.
