How to deal with the broken wire of the Shale shaker screen

How to deal with the broken wire of the vibrating screen? The vibrating screen will be damaged during use. We need to find out the reason for the damage in time, and we can avoid secondary damage to the screen when it is being processed.

The screen is one of the main components of the vibrating screen. It is in direct contact with the screening medium during the production process, which causes the phenomenon of rapid damage to the vibrating screen. It can classify materials of different particle sizes. The main vulnerable parts of the vibrating screen, but due to our selection and other reasons, the phenomenon of rapid damage to the vibrating screen has occurred. Now we will discuss the reasons for the rapid damage of the vibrating screen and propose corresponding solutions.


Screens are generally rolled up during the process of manufacturing, transportation and storage. The transverse stainless steel wires of the screen are many beams subjected to bending loads. The inner side is subjected to compressive stress and the outer side is subjected to tensile stress. When the screen is installed on the screen frame, these bending internal stresses have not been eliminated.-The circular Shale shaker screen, but due to our selection and other reasons, part of the screen tension is used to overcome the bending stress generated by the screen wire, in order to straighten the screen.

After the screen has been used for a period of time, the screen will become loose, causing insufficient tension of the screen, resulting in serious stress concentration, and secondary vibration. The screen wire is repeatedly bent and the plasticity is getting smaller and smaller. After that, the screen wire will be brittle fracture and damage, and the screen will be broken in the middle. Even if it does not break, the screen material will yield due to the increased load of drill cuttings during use, and the screen will be partially dented and debris will accumulate, which will cause the screen to be destroyed. Linear vibrating screen, vertical and horizontal airflow screens. Solution: If the screen is damaged too quickly due to insufficient tension of the screen, we can appropriately increase the tension of the screen to keep the screen surface flat, so that the screen is flat.

Xi'an HL produces various screens, soft crocheted screens, Derrick flat screens, steel frame screens, and frame composite screens. Welcome to send inquiry to us: sales@hlsolidscontrol.com if you have purchase request of shale shaker screens.
