How many motions does the vibrating motor of the mud shale shaker have

The motion of the vibrating motor of the mud shale shaker is different, the vibrating screen will have a different motion, and the type of the vibrating screen is different for different motions. Today, the editor of HL will tell you what kinds of motions are available for the vibrating motor.

The motion of the mud vibrating screen depends on the installation position, vibration direction and mesh number of the vibrating motor used. In any case, the correct vibration direction must be determined first.

Linear motion vibrating screen:

Most linear motion vibrating screens use dual vibrating motors, which rotate in opposite directions and are installed in parallel. The direction of movement and the angle of installation must be determined in advance. This kind of vibration motor adopts integral type, sealed type, belt transmission, gear transmission and other forms for design.


Balanced elliptical vibrating screen:

The balanced elliptical vibrating screen adopts double vibrating motors, which rotate in opposite directions and form a certain angle, which is not parallel. In order to obtain the designed angle and direction, the vibration motor must be installed correctly. The direction of the elliptical motion track must be inclined toward the direction of the discharge port, and cannot face the drilling fluid tank. When the quality of the two vibration motors installed on the linear vibrating screen is different, and other installation methods are similar, the motion track becomes an elliptical type.

Unbalanced elliptical vibrating screen:

The unbalanced elliptical motion vibrating screen has only one vibrating motor, which is installed at the center of gravity of the vibrating screen. This flameproof vibration motor is designed in the form of integral, sealed, belt drive, hydraulic drive, etc.

Xi'an HL produces and processes linear vibrating screens, circular vibrating screens, elliptical vibrating screens, laminated vibrating screens and balanced elliptical vibrating screens, etc., welcome to send inquiry to us: sales@hlsolidscontrol.com if you want to know more about shale shakers.
