How to deal with the head and flow drop of HJQ56J shear pump?
Time: 2023-08-10 Source: Author: hlsolidscontrol
1. Large particles block the suction pipe and impeller flow path: Large particles may block the suction pipe and impeller flow path of the pump, resulting in a drop in pump flow. The solution is to remove the blockage and ensure that the suction pipe and impeller flow path are unblocked.
2. Decrease in pump speed: If the pump speed is reduced, it will result in a decrease in pump flow and head. The solution is to ensure that the pump is running at rated speed, and the driving part of the pump may need to be adjusted or repaired.
3. Impeller wear: The wear of the impeller will affect the performance of the HJQ56J shear pump, resulting in a decrease in flow rate and head. The solution is to replace the impeller to restore the normal working condition of the pump.
4. The gap between the impeller and the end face of the pump casing is too large, and the leakage increases: If the gap between the impeller and the end face of the pump casing of the HJQ56J shear pump is too large, the efficiency of the pump will decrease and the leakage will increase, thereby affecting the flow rate and head. The solution is to adjust the gap between the impeller and the end face of the pump casing to ensure a good sealing performance.
5. The inlet valve opening is too small: The inlet valve opening is too small to restrict the fluid from entering, thereby reducing the flow rate of the pump. The solution is to properly open the inlet valve to ensure that enough fluid can enter the HJQ56J shear pump.
When dealing with the above problems, please be sure to follow the relevant operating procedures and safety guidelines to ensure safe operation and normal operation of the HJQ56J shear pump. If the problem persists or cannot be resolved, it is recommended to seek help from professional technical support or equipment maintenance personnel.
