What to pay attention to when choosing a Shale shaker screen

1. In the normal selection of shale shaker screen, try to choose 304 or 316L stainless steel screens, because they are more wear-resistant, waterproof and moisture-proof. If the screen aperture is too large and the cost is too high, you should choose manganese steel or a material with a higher hardness. It is not recommended to choose a Q235 screen because it is easy to deform.

2. The choice of screen. First select the replacement screen, and the size specifications must be consistent with the original screen. Secondly, choose a good quality screen, which has a long service life and is not easy to damage. Moreover, this screen can not only greatly improve the efficiency of material screening, but also help prolong the life of the vibrating screen equipment.

3. After confirming the width of the sieve before purchasing the sieve, it should be about 50mm wider than the sieve when cutting the sieve, so that it is more worry-free when installing.

4. When installing the screen, pay attention to the tightness of the screen. Too loose materials will stop rotating in place, and the tightness of the screen should be suitable if it is easy to break.

5. When the wire diameter of the installed screen is too small, a layer of trawl should be added to the screen to increase the life of the Shale Shaker. , Generally, trawl nets should be added for more than 60 meshes.

6. Pave the screen. After selecting the Shale Shaker, when installing the screen, the screen should be laid flat on the pallet, and the screen should be evened. Pay attention to the strength when pulling, and the screen should not be broken or deformed, which will cause influence Use later. It is then fixed on the grid.

7. When installing the net frame, the front and back should be distinguished. The wooden net frame should be aligned front and back, and the top and bottom should be pressed tightly. When installing, use a rubber hammer to lightly hit the net frame. Pay attention to tighten the screws on the iron grid frame, otherwise it will cause leakage.

8. After the screen is installed, the screen should be tested first. Test the screen with a little material to see the tightness of the screen.

9. Pave the screen. After selecting the Shale Shaker, when installing the screen, the screen should be laid flat on the pallet, and the screen should be evened. Pay attention to the strength when pulling, and the screen should not be broken or deformed, which will cause influence Use later. It is then fixed on the grid.
