What are the factors that affect the working efficiency of the cyclone

In the production process of hydrocyclones, the factors that affect their working efficiency mainly include two aspects: material feeding parameters and overflow and sand discharge methods. If you want to maintain the stable and efficient operation of the equipment, you need to be familiar with the reasonable operation skills of the two aspects of the hydrocyclone. In daily production, keeping the process operating parameters within a reasonable range can effectively ensure the stability of the hydrocyclone. run.

Factors affecting the working efficiency of the cyclone:

1. The supply pressure of the equipment and the concentration and particle size composition of the materials.

The feed pressure set by the equipment mainly affects the processing capacity and grading particle size of the hydrocyclone. When the feed pressure increases, the slurry flow rate will increase, the viscosity effect will decrease, and the hydrocyclone classification effect will be improved. When processing coarse-grained materials, most concentrators use 49-98KPa low pressure; when processing fine-grained and muddy materials, they use 98-294KPa high pressure.

The concentration and particle size composition of the feed mineral material will directly affect the concentration and particle size of the final product. The coarser the grading particle size, the more the mud content or fine-grained grade in the grading material, the higher the ore concentration should be, and the greater the slurry viscosity. , The coarser the granularity of the overflow product.

2. The discharge method of overflow and sedimentation.

In the ideal working state of the hydrocyclone during work, the material should be sprayed out of the sand in an umbrella shape, and the angle of the umbrella surface should not be too large, so that it can just spread out. When the hydrocyclone is used for thickening operations, the concentration of the sediment will be higher when it is discharged in a rope shape; when the hydrocyclone is used for dehydration operations, the sediment will be discharged in a larger umbrella shape, and the overflow will contain solids. The amount is reduced.

The above are the two use factors that affect the working efficiency of the hydrocyclone. However, it is worth noting that hydrocyclones are affected by many aspects in production. When the efficiency of the equipment decreases, we should make specific analysis according to the specific situation. Only by considering the overall situation and working closely together can we obtain the ideal working efficiency. If you encounter a problem that is difficult to solve in the use of the equipment, please send inquiry to us sales@hlsolidscontrol.com and we will design a reasonable solution for you!
