22223-01-30, 641116157 Stuffing Box, Mech. Seal for Mission Magnum Centrifugal Pump

HL Petroleum offers Mission Magnum 8x6x14 Charging Pump with stuffing box, mechanical seal 641116157 / 22223-01-30 which easy to replacebale.

• Pump model: From 3x2x13 to 8x6x14

• Part code: 22223-01-30

• Part #: 641116157

• Material: Hard Iron

• Weight: 20 kgs

An easily removable stuffing box allows these pumps to be customized to meet customer needs. The different options available are stuffing boxes to accommodate:

• Shaft packing

• Single mechanical seal

The packed box has a tapped opening to the lantern ring to allow grease lubrication or a flush line to be attached.

Dual stuffing box bolts are positioned 180 degrees apart to hold the stuffing box in position during casing removal. When only one stuffing box bolt is used the stuffing box remains in position on one side while the other side moves with the casing, causing the casing to bind and make removal difficult.
