Mud Cooling Device

Product details

The drilling mud cooler, also known as mud cooling device, mud cooling system, etc., is generally erected in the mud pool to cool the high-temperature mud. The basic principle of the cooling system and the fan to cool the mud is to manipulate the air and the mud indirectly, and take away the heat in the mud through evaporation, and the cooling medium is air. The mud cooling system is a special equipment used to cool the high temperature mud in the well during the drilling process. It is currently a relatively efficient and safe mud cooling method.

Mud Cooling Device Working Principle

When working, the sand pump extracts the mud from the mud tank and discharges it to the cooling tank spray system. Relying on the electric fan on the top, the cold air outside the tank is forcibly sucked into the tank through the lower part of the tank; the hot mud is evenly distributed from the upper spray system. Each nozzle sprays the hot mud down onto the filler layer through the nozzle, forming a water film on the filler, the mud and the cold air entering the tank exchange heat in the filler; the hot and humid air is discharged out of the tank by the fan, and the cooling mud enters drain from the sink.

Mud Cooling Device Features

In view of the difference in mud temperature in different countries and areas, Xi'an HL Petroleum has developed specific characteristics that can meet the different temperature rises of mud in different formations, and developed mud cooling equipment: rapid mud cooling equipment and ordinary mud cooling equipment.

This equipment is aimed at the continuous high temperature of the drilling fluid during the drilling process, resulting in high temperature degradation, high temperature cross-linking, high temperature desorption and other phenomena of the drilling fluid. It is a drilling fluid cooling device that quickly cools the high temperature drilling fluid returned downhole on the ground .

The device can ensure that the drilling fluid maintains stable performance at a suitable temperature to ensure normal drilling and is suitable for mud cooling; natural gas hydrate; permafrost drilling; oil and gas drilling; geothermal drilling.
